Yodsak Tube Fittings, based in Bangkok, Thailand, has earned a solid reputation as a reliable manufacturer and supplier of Stainless Steel 316 Hydraulic Fittings. These fittings are specifically designed for high-performance hydraulic systems across a range of industries. Renowned for their quality, precision, and durability, Yodsak’s products adhere to strict international standards, ensuring they perform consistently in high-pressure and corrosive environments. Catering to sectors like marine, oil & gas, construction, chemical processing, and heavy machinery, Yodsak maintains top-notch product quality through advanced manufacturing techniques and thorough quality control. With a strong presence in both domestic and international markets, Yodsak Tube Fittings provides secure, leak-free hydraulic solutions tailored for demanding applications.
Stainless Steel 316 Hydraulic Fittings are crafted from molybdenum-bearing austenitic stainless steel, featuring a composition of Chromium (16–18%), Nickel (10–14%), and Molybdenum (2–3%). This unique alloy offers exceptional corrosion resistance, particularly against chlorides, acidic fluids, and harsh industrial chemicals. The material boasts impressive mechanical properties, including high tensile strength (around 515 MPa), yield strength (minimum 205 MPa), and excellent elongation (~40%), ensuring reliable performance even under high-pressure conditions. Additionally, Stainless Steel 316 maintains its toughness across a wide range of temperatures, making it an ideal choice for hydraulic systems that face temperature variations and challenging environmental conditions.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | SS 316 ,SS 316L |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| TEMPERATURE | STAINLESS STEEL 316 – (-60*C TO 400*C) |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
Grade | Mn | C | S | Mo | N | Si | P | Cr | Ni | |
316 | Minimum | – | – | – | 2.00 | – | – | 0 | 16.0 | 10.0 |
Maximum | 2.0 | 0.08 | 0.03 | 3.00 | 0.10 | 0.75 | 0.045 | 18.0 | 14.0 | |
316H | Minimum | 0.04 | 0.04 | – | 2.00 | – | 0 | – | 16.0 | 10.0 |
Maximum | 0.10 | 0.10 | 0.03 | 3.00 | – | 0.75 | 0.045 | 18.0 | 14.0 |
Grade | Elong (% in 50mm) min | Yield Str 0.2% Proof (MPa) min | Tensile Str (MPa) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
316 | 40 | 205 | 515 | 95 | 217 |
316H | 40 | 205 | 515 | 95 | 217 |
Grade | British | Euronorm | UNS No | SS | JIS | ||
European Standards | British Standards | DIN No | Name | ||||
316 | 58H, 58J | 316S31 | 1.4401 | X5CrNiMo17-12-2 | S31600 | 2347 | SUS 316 |
316H | – | 316S51 | – | – | S31609 | – | – |
Contact us to get a quick quote for your requirement.
Stainless Steel 316 Hydraulic Fittings find extensive use in hydraulic systems where high pressure, corrosion resistance, and long-lasting reliability are essential. Their applications range from marine vessels and offshore platforms to oil and gas pipelines, chemical processing plants, food and beverage manufacturing, and mobile heavy equipment. These fittings play a crucial role in connecting hoses, tubes, and pipes within systems that transport fluids under demanding conditions.
Please feel free to contact us if you need any further information or for enquiry.
