Home > Super Duplex Steel > Super Duplex Steel S32760 Tube Fittings
Yodsak Tube Fittings, based in Bangkok, Thailand, stands out as a top manufacturer and supplier of precision-engineered tube fittings designed for high-performance and corrosive settings. Among their top-notch products are the Super Duplex Steel S32760 Tube Fittings, crafted to handle the most demanding requirements of critical fluid and gas systems. Renowned for their remarkable strength, resistance to corrosion, and leak-proof reliability, these fittings find extensive use in offshore, petrochemical, and marine sectors. Yodsak is dedicated to providing high-quality, cost-effective solutions that adhere to global standards, prioritizing durability, safety, and customer satisfaction even in the toughest industrial environments.
Yodsak’s Super Duplex Steel S32760 Tube Fittings are crafted from the UNS S32760 alloy, a high-performance super duplex stainless steel that contains about 25% chromium, 7% nickel, 3.5% molybdenum, along with trace amounts of tungsten and nitrogen. This unique blend offers exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, particularly in chloride-rich settings. The material boasts impressive mechanical strength, featuring a tensile strength of around 800 MPa and a yield strength of about 550 MPa. These fittings are designed to withstand high pressure and temperature, making them perfect for demanding environments that require secure and durable tube connections.
| Tube Size | 1/16”OD to 2”OD, 2mm OD to 50mm OD |
| Material Grades | Super Duplex Steel S32760 |
| Thread | NPT, BSP, BSPT, UNF, ISO, SAE etc. |
| Pressure Rating | 6000PSI for Super Duplex Steel, 300/1000/3000PSI for Brass |
| Standards | ASTM D1710, ASTM D3294 |
| Applicable temperature | 150-400°C |
At Yodsak Tube Fittings, we are the largest supplier, manufacturer, and exporter of Super Duplex Steel S32760 Tube Fittings in Bangkok, Thailand. Our advanced manufacturing facilities, strategically positioned in the Thailand, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| Grade | S32750 | S32760 |
| C | 0.030 max | 0.05 max |
| Mn | 1.20 max | 1.00 max |
| Si | 0.80 max | 1.00 max |
| P | 0.035 max | 0.030 max |
| S | 0.020 max | 0.010 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Mo | 3.00 – 5.00 | 3.00 – 4.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| N | 0.24 – 0.32 | 0.20 – 0.30 |
| Fe | 58.095 min | 57.61 min |
Contact us to get a quick quote for your requirement.
Super Duplex Steel S32760 Tube Fittings are extensively utilized in critical applications where high mechanical strength and outstanding corrosion resistance are crucial. They are particularly well-suited for offshore oil and gas platforms, subsea systems, desalination plants, petrochemical facilities, and marine environments. These fittings excel in high-pressure fluid transport, especially in aggressive media like saltwater, brine, and acidic or alkaline conditions.
Please feel free to contact us if you need any further information or for enquiry.
