Yodsak Tube Fittings, located in Bangkok, Thailand, has earned a solid reputation as a reliable manufacturer and supplier of top-notch fluid and gas control components. One of their standout products is the Bulkhead Union Elbow, known for its impressive durability, leak-proof design, and straightforward installation in intricate piping systems. Built to comply with international standards, Yodsak’s fittings find their place in various settings, including industrial, commercial, and laboratory environments. The company is dedicated to providing dependable and cost-effective solutions, prioritizing product performance, customer satisfaction, and safety across diverse industries like oil and gas, chemical processing, and manufacturing.
When it comes to the Bulkhead Union Elbow from Yodsak Tube Fittings, it’s typically crafted from high-quality stainless steel (SS316/SS304), brass, or carbon steel, tailored to meet specific application requirements. This fitting boasts remarkable corrosion resistance, mechanical strength, and temperature resilience. Its mechanical properties include a high tensile strength of up to 515 MPa, an elongation rate of 30%, and a hardness level ranging from 80 to 100 HRB. Designed to handle pressure ratings of up to 6000 psi, it guarantees leak-tight connections even in high-stress situations. Each component is precision-machined and rigorously tested to ensure dimensional accuracy and consistent performance under challenging conditions.
| Mcneil part no. | Equivalent Part no. Type 1 | Equivalent part no Type 2 | ODT-ØT(INCHES) | C | BODY HEX F | ODT-ØT1(INCHES) | Ø E | D | L | NUT HEX W | L1 |
| 1-BUD | -100-61 | 1BC1 | 1/16 | 0.43 | 5/16 | 1/16 | 0.05 | 0.34 | 0.84 | 5/16 | 1.24 |
| 2-BUD | -200-61 | 2BC2 | 1/8 | 0.60 | 7/16 | 1/8 | 0.09 | 0.50 | 1.50 | 7/16 | 2.02 |
| 3-BUD | -300-61 | 3BC3 | 3/16 | 0.63 | 9/16 | 3/16 | 0.12 | 0.54 | 1.59 | 7/16 | 2.11 |
| 4-BUD | -400-61 | 4BC4 | 1/4 | 0.70 | 5/8 | 1/4 | 0.19 | 0.60 | 1.03 | 9/16 | 2.27 |
| 5-BUD | -500-61 | 5BC5 | 5/16 | 0.73 | 11/16 | 5/16 | 0.25 | 0.64 | 1.81 | 5/8 | 2.39 |
| 6-BUD | -600-61 | 6BC6 | 3/8 | 0.76 | 3/4 | 3/8 | 0.28 | 0.66 | 1.87 | 11/16 | 2.45 |
| 8-BUD | -810-61 | 8BC8 | 1/2 | 0.86 | 7/8 | 1/2 | 0.41 | 0.90 | 2 | 7/8 | 2.80 |
| 10-BUD | -1010-61 | 10BC10 | 5/8 | 0.86 | 1-1/16 | 5/8 | 0.50 | 0.96 | 2.06 | 1 | 2.86 |
| 12-BUD | -1210-61 | 12BC12 | 3/4 | 0.86 | 1-3/16 | 3/4 | 0.63 | 0.96 | 2.31 | 1-1/8 | 3.11 |
| 14-BUD | -1410-61 | 14BC14 | 7/8 | 0.86 | 1-3/8 | 7/8 | 0.72 | 1.02 | 2.53 | 1-1/4 | 3.33 |
| 16-BUD | -1610-61 | 16BC16 | 1 | 1.04 | 1-5/8 | 1 | 0.88 | 1.23 | 2.81 | 1-1/2 | 3.77 |
Yodsak Tube Fittings is a leading supplier and stockist of premium Bulkhead Union Elbow in Bangkok, Thailand. Our products are widely utilized across various industries, recognized for their strength, durability, and reliable performance in connecting multiple pipe sections. We are committed to delivering exceptional service and ensuring high levels of customer satisfaction. Our advanced manufacturing techniques set us apart in the fittings industry, enabling us to consistently provide top-quality Union Cross fittings while effectively addressing the unique requirements of our customers.
Contact us to get a quick quote for your requirement.
The Bulkhead Union Elbow is a go-to solution for connecting two tubes at a 90-degree angle through a panel or enclosure, providing a secure and leak-proof joint. It’s perfect for scenarios where tubing needs to navigate through walls or tanks while keeping the flow direction intact. You’ll often find it in hydraulic and pneumatic systems, process instrumentation, chemical transfer lines, gas distribution networks, and oil refineries, where it offers both stability and structural support. Its sturdy construction enables it to endure high-pressure environments with ease.
