700 Bar Hydraulic Fittings are top-notch connectors crafted to handle extreme pressures of up to 700 bar (10,150 psi) in hydraulic systems. Made from high-quality materials like stainless steel, carbon steel, or alloy steel, these fittings ensure secure, leak-proof connections for critical high-pressure tasks. They’re designed with precision to maintain system integrity, prevent leaks, and guarantee safe and efficient fluid transfer. You’ll find 700 Bar Hydraulic Fittings in heavy industrial machinery, construction equipment, oil and gas operations, marine systems, and power generation, where reliability and safety under high pressure are a must.
These fittings boast remarkable mechanical properties, including ultra-high tensile strength, toughness, and resistance to fatigue, vibration, and pressure surges. Thanks to precision machining, they feature leak-proof threads and sealing surfaces, ensuring dimensional stability even in extreme conditions. Plus, they resist wear, corrosion, and mechanical stress, offering a long service life in tough hydraulic environments. Their sturdy construction means they perform reliably, even when faced with fluctuating high-pressure loads.
| BRAND | Yodsak Tube Fittings |
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20 |
| SERIES | S- HIGH PRESSURE |
| WORKING PRESSURE | (HEAVY) S SERIES – 200 BAR TO 800 BAR |
| SIZE RANGE | S SERIES – 6S TO 38S |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TOADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| ACCESSORIES | O-RING, DOWTY SEAL , COPPER WASHER , ED SEAL, CUTTING RING , NUT |
| O-RING & SEALS | NBR ( -35*C TO 100* C ) VITON (-25*C TO 200* C) , PTFE – (-60*C TO 240*) |
| SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED, |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH | |
| TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
| EQUIVALENT BRANDS | PARKER, HY-LOK , DK-LOK , STAUFF, HYDAC , VOSS |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
| STEEL – ASTM 108/A105, JIS G4051 S20C, S45C,/G3201 SF440A. | |
| BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
You’ll see 700 Bar Hydraulic Fittings used extensively in ultra-high-pressure hydraulic circuits, industrial machinery, mobile equipment, offshore installations, and oilfield applications. They’re perfect for connecting hoses, tubes, and pipelines in systems where handling extreme pressure, preventing leaks, and ensuring operational safety are crucial. By providing strong, reliable, and corrosion-resistant connections, these fittings safeguard sensitive equipment, cut down on maintenance needs, and boost system efficiency. With their blend of strength, durability, and precision, 700 Bar Hydraulic Fittings are indispensable for high-pressure hydraulic applications.
Yodsak Tube Fittings is a leading supplier and stockist of premium 700 Bar Hydraulic Fittings in Bangkok, Thailand. Our products are extensively utilized across various industries, recognized for their high pressure tolerance, durability, and reliability. We are dedicated to delivering exceptional service and ensuring high levels of customer satisfaction. Our innovative manufacturing techniques set us apart in the hydraulic fittings market, enabling us to consistently provide top-quality 700 Bar Hydraulic Fittings while efficiently addressing the unique needs of our customers.
Contact us to get a quick quote for your requirement.
700 Bar Hydraulic Fittings are essential in various high-pressure applications across multiple industries. They are widely used in oil and gas exploration, where reliable connections are crucial for the transportation of fluids and gases. In the aerospace sector, these fittings support hydraulic systems in aircraft, ensuring optimal performance and safety. Additionally, they are utilized in heavy machinery and industrial equipment, providing robust connections that can withstand extreme conditions. Their ability to maintain pressure integrity makes them ideal for hydraulic presses and test rigs, enhancing operational efficiency and safety.
